Cross flow microfiltration unit
Cross flow microfiltration unit
or
Call +49 (0) 8161-48333
Description
The Filtrox Cross Flow microfilter works with a permissible transmembrane pressure of 6 bar (0 °C - 95 °C) and a filtrate volume of 4.5 - 7 hl/h with a filter surface area of 26.4 m².
Two pumps (20 kW) in the unfiltrate circuit transport the medium to be filtered. With 16 hl agitator tank as cleaning tank.
Specifications
| Manufacturer | FILTROX AG |
| Year | 1991 |
| Condition | Used |
| Stock Number | 205225ZM |
| Additional title | membrane filtration plant for yeast-beer recovery 1987-1991 |
| Capacity | 7 hl/h |
| Tol. operating pressure | 10 bar |
| Tol. operating temperature | 85 °C |
| Max. filter area | 26 m^2 |
| Current | 4,85/2,8 A |
| Voltage | 220/380 V |
| Frequency | 50 Hz |
| Operation / Control | Simatic S5 |
| Features | 8 ceramic membrane modules (total filtration area 26.4 m2); high-pressure pump; 16 hl cleaning tank with agitator; various pipes, valves, measurement and control technology |
