Paramix system with carbonation unit; 2010 (overhauled and modernized)

Paramix system with carbonation unit; 2010 (overhauled and modernized)

or
Call +49 (0) 8161-48333

Description

PARAMIX unit for carbonated drinks. The included process steps are: Deaeration of water, dosing and mixing of water and syrup, carbonating of water-syrup blend. Retrofit 2009 by FAMIX: - Carbonating device - CO2 pressure-temperature ratio controller Type BMS7 The controller including control cabinet is to be completely renewed when the machine is purchased.
Show All

Specifications

ManufacturerHolstein und Kappert
Year2010
ConditionUsed
Stock Number205396ZM-1
Additional titlemixing unit 1983 - 2010
Capacity approx.150 hl/h Mixing and carbonating
Length2,9 m
Width2,5 m
Height2,5 m
Weight3000 kg
Operation / Controlmixing unit semi automatic, carbonating unit automatic Siemens S7
MaterialStainless steel
PositionFrame mounted
Features2 pressure vessels (Product und Vacum), each 8,3 hl/ 8 bar, CO2-Pressure-Temperature regulator (FAMIX BMS7), Carbonising unit (FAMIX) Capacity 13000 l/h, PT 100, Pressure sensor, Pressure relief valve, CIP connection, control cabinet, HMI (Siemens), 2 mixing vessels with flap and agitator (Ahlborn, approx. 15 hl per vessel)
