Pressure tanks (4 pcs.)
Pressure tanks (4 pcs.)
or
Call +49 (0) 8161-48333
Description
Pressurised tank cellar with 4 upright 324 hl stainless steel pressure tanks and with double-seat valve solution on the operating level.
The tanks are cooled using ice water.
Specifications
| Manufacturer | GROSS Behälterbau GmbH |
| Year | 1985 |
| Condition | Used |
| Stock Number | 208200HN |
| Additional title | coolable stainless steel pressure tanks |
| Volume per tank | 32400 l |
| Cooling surface/tank | 25 m² |
| Perm. working overpressure | 3 bar |
| Systemic volume | 324 hl |
| Length | 2,5 m |
| Width | 2,5 m |
| Height | 7,4 m |
| Weight | 2585 kg |
| Material | stainless steel AISI 304 |
| Features | Tank cleaning equipment with spray head, safety valve, pressure gauge, air valve combination; sampler, level indicator with valves, outlet valve |
| Periphery | Inlet and outlet pipework via double-seat valves |
