Empty bottle inspector
Empty bottle inspector
or
Call +49 (0) 8161-48333
Description
Inspection machine for detecting damage and contamination in glass bottles, as well as for identifying foreign bottles.
Specifications
| Manufacturer | Krones AG |
| Year | 1991 |
| Condition | Used |
| Stock Number | 204228CK |
| Nominal capacity of filler | 60000 b/h |
| Power | 10,7 kW |
| Water | max. 4 bar, consumption: 1,3 l/min |
| Compressed air | 6 bar, consumption: 2,5 bar, 30 N/m³/h |
| Length | approx. 2.995 mm |
| Width | approx. 2.370 mm |
| Height | approx. 2.600 mm |
| Weight | 5200 kg |
| Formats | 0,33 l LongNeck-, 0,5 l NRW-bottles, bottle height: min. 150 mm/ max. 350 mm, diameter: 71 mm |
| Machine partitioning | 94 mm |
| Operation / Control | Siemens S5 |
| Features | inspections: bottom inspection, mouth inspection, sidewall inspection, caustic detection High frequency, residual fluid detection Infrared, evaluation for detection and separation of bottles with heavy abrasion, height detection |
