Description
Empty bottle inspector for monitoring empty glass bottles. The machine uses cameras, high frequency, and infrared to inspect the following criteria:
- Contour, height, color
- Side wall
- Residual lye detection
- Mouth
- Thread
- Residual liquid detection
- Bottom inspection
- Glass shards and film detection
- Sealing surface inspection
Bottles that do not meet the specifications are ejected via pushers.
Specifications
| Manufacturer | Krones |
| Year | 2017 |
| Condition | Used |
| Stock Number | 210438MW |
| Additional title | Straight-running machine in modular design |
| Current | 6 A |
| Voltage | 400 / 230 V |
| Frequency | 50 Hz |
| Water | 3 - 5 bar |
| Compressed air | 6 - 10 bar, 1/2" connection |
| Length | 2980 mm |
| Formats | 1.0 L and 0.2 L VdF bottles, 0.5 L NRW bottles |
| Running direction | right -> left |
| Operation / Control | Simatic S7-300 |
| Position | standing on feet |
| Base construction | straight-running |
| Features | camera, side wall modules, test bottle detection, high-frequency and infrared inspection, side opening inspection, thread inspection, sealing surface inspection, light barrier, pushers at inlet and outlet, diversion control, operating panel |
