Yeast tank
Yeast tank
or
Call +49 (0) 8161-48333
Description
Cylindrical-conical stainless steel tank with magnetic stirrer and various fittings. The frame and cone can be cooled using cooling pockets filled with glycol. The stainless steel surfaces have been matt pickled on the inside and cleanly ground on the outside.
Wall thicknesses:
- Cone 3 mm
- Frame 2 mm
- Clamp bottom 3 mm
Cone angle: 60 °
Roughness of cone interior < 0.35 µm
Specifications
| Manufacturer | Kaspar Schulz |
| Year | 2002 |
| Condition | Used |
| Stock Number | 210631MW |
| Additional title | Vertical, coolable, cylindroconical stainless steel tank with agitator |
| Gross volume | 1400 l |
| Operating pressure | 0,99 bar |
| Length | 1000 mm |
| Width | 1000 mm |
| Height | 3000 mm |
| Material | V2A stainless steel 1.4301 (AISI 304) |
| Position | standing on 3 feet |
| Base construction | cylindrical-conical, upper bottom dished |
| Features | Frame and cone cooling; magnetic stirrer with gear motor; ladder support bracket; outlet pipe with manual valve; DN100 sight glass; DN15 sampling tap; safety fitting with safety valve, pressure gauge and flap valve); CIP spray head; 2-hole cleaning air valve combination (Handtmann brand) |
