Description
Water treatment plant with semi-permeable membrane modules for desalinating pre-treated water. Reverse osmosis takes place via a two-stage process consisting of two pressure pipes, each with two membrane modules.
The plant consists of:
- Two pressure pipes, each with two membrane modules
- Permeate blending and concentrate recirculation
- Upstream fine filtration
- Various sampling taps
- Various measuring instruments for pressure, flow, temperature, conductivity and pH value
- Flushing station with flushing tank and flushing pump
- Chemical dosing stations for antiscalant and NaOH
- High-pressure pump
- Various automatic fittings
- Control cabinet with touch display
Specifications
| Manufacturer | Veolia |
| Year | 2016 |
| Condition | Used |
| Stock Number | 210633MW |
| Additional title | Reverse osmosis for desalination of raw water |
| Flow rate | 6000 l/h depending on the blending quantity |
| Max. operating overpressure | 14 bar |
| Recovery appr. | 82 % |
| Water | 5-7 m3/h; 1-10 bar |
| Operation / Control | Switch cabinet with touch display |
| Features | 2 pressure pipes, each with 2 membrane modules; sampling taps; fine filters; flushing stations; chemical dosing stations; high-pressure pump; automatic fittings; measurements of pressure, flow, conductivity, temperature and pH value; |
