Centrifugal Pump
Centrifugal Pump
or
Call +49 (0) 8161-48333
Specifications
| Manufacturer | KSB SE & Co. KGaA |
| Year | 2012 |
| Condition | Used |
| Stock Number | 205635SS |
| Pump capacity | 14 m³/h |
| Max pump head | 6 m |
| Rotational speed | 1450 U/min |
| Power | 3.0 kW |
| Voltage | 400/690 V |
| Frequency | 50 Hz |
| Heating / Cooling | -30°C to +140°C |
| Material | Volute case, pump cover and impeller made of cast iron EN-GJL-250, shaft 1.0503/AISI 1045 |
| Position | Due toInlaydesign horizontal and vertical installation possible |
| Features | Suction/pressure side with DN65 flange fitting, 4 Pol Norm-Motor, 160mm impeller diameter Rigid motor-shaft connection, mechanical seal, grooe ball bearing |
