Description
Unpacker
Manufacturer: SZA Federspiel
Model: SP 1600-A
Bottle holder: 4x20 or 4x24 bottles
Year of manufacture: 2001
Specifications
| Manufacturer | SZA Federspiel |
| Year | 2001 |
| Condition | Used |
| Stock Number | 209865HG |
| Additional title | crate unpacker |
| Capacity | 30000 bottles/h |
| Air consumption | 4 m³/h |
| Current | 16 A |
| Voltage | 230/400 V AC |
| Compressed air | 5 bar |
| Length | 2500 mm |
| Width | 2500 mm |
| Height | 2400 mm |
| Formats | 0.33 l Vichy, 0,33 l Euro, 0.35 l lemonade, 0.5 l NRW bottles, modular crate, 8 packing heads (4x20 and 4x24) |
| Running direction | modul crates lengthwise, from right to left |
| Operation / Control | Simatic S7-300 / OP17 |
| Position | free standing |
| Base construction | Square frame construction painted on dome feet |
| Features | Gripper head carrier with pneumatic equipment, operating area covered with windows, container transport, bottle transport, 2 gripper head sets, safety equipment, electrical and pneumatic equipment |
